Productivity PLC Suite Software - View Desktop There are two methods to access Show Desktop: Method 1 Select Show Desktop from the Tools menu of the Main Menu. Method 2 Select the Show Desktop Icon located in the Layout Toolbar. Show Desktop gives you the ability to expand the viewing area of the Ladder Logic Editor. It gives you the ability to see all of your ladder logic, and still have all the options quickly available. Selecting Show Desktop expands the Logic Editor width and places the Application Tools, Task Manager, and Instructions panels in a tab format along the sides of the Logic Editor. Programming and examples of the Productivity series can be found at this URL: https://accautomation.ca/series/productivity-1000-plc/ Productivity offers three distinct form factors with two being rack-based and one being stackable. Each series offers different I/O capacities but all use the same programming software, allowing you to easily scale your control up or down depending on the application or machine building. The Productivity Suite software provides versatile programming with tag name addressing that has no predefined memory structure, and offers convenient device integration for easy plug-and-play operation with our PS-AMC motion controllers, GS drives, Protos X field I/O, and StrideLinx VPNs. A few of the Features: - Tag name-based programming with 50MB user memory - Numerous built-in communication options including Ethernet, serial, USB, remote, and local expansion - Web server and mobile access - OLED/LCD module data displays (P2000/P3000) - Integrated motion controller, GS drive, StrideLinx VPN, and Protos X field I/O support - External microSD data logging - Scalable platforms from 128 to over 59K I/O points with analog, discrete, pulse width modulation, and high-speed options - ABS certified for marine applications (P2000/P3000) - Project simulator - Easy-to-use coordinated motion control with the PS-AMC motion controllers and built-in motion instructions General information on the Productivity PAC series of controllers: https://www.automationdirect.com/adc/overview/catalog/programmable_controllers/productivity_series_controllers PLC (PAC) Selector and Configuration: https://www.automationdirect.com/systembuilder #shorts ACC Automation https://accautomation.ca/
