Instrumentation & Control Engineering - Instrument Cable Tray / Trench Layout (Part -12I)

Introduction: As part of Construction Engineering, while preparing the instrument cable tray / trench routing as a construction layout the following basic information is required. #InstrumentCableTrayLayout #InstrumentCableTrenchLayout #TrayLayout #CableRouting 1) Overall plot plan for marking the details of all equipment Skids and packages are to be installed as per the overall plot plan, as shown in figure shown in this video. 2) Planning can be started for instrumentation construction work, e.g., preparing the cable trench tray routing layout, JB location and instrument locations. 3) The minimum tray/trench routing, elevation and type of cable tray, size of tray and all the detailed sections are generally shown. 4) The construction engineering is done to minimize the time & effort during the construction phase when the actual implementation of approved drawings/ documents is carried out. It minimizes errors such as, mismatching of cable routing, tray/trench work and safety precaution etc. Note: Keep watching our channel eFunda where we are creating videos related to Engineering and Project Topics and saved under separate play List. 1) Fundamentals https://www.youtube.com/playlist?list=PLLKo6f5HHKAdaT9ZgNsl3iO4i9qm05tTL 2) Project / Career https://www.youtube.com/playlist?list=PLLKo6f5HHKAcJ_NvjjUdmmjK-GIHF-fjo 3) Engineering https://www.youtube.com/playlist?list=PLLKo6f5HHKAfupB6q9S6a-RhBmNl2AMcb 4) Instrumentation & Control Engineering https://www.youtube.com/playlist?list=PLLKo6f5HHKAfCDQLRRC22u8flW7KFJjwF 5) Historical / Social https://www.youtube.com/playlist?list=PLLKo6f5HHKAfC0lYQKglDOfux9dRAjfrd Please follow us: eFunda Instagram – https://www.instagram.com/efundachannel/ Facebook - https://www.facebook.com/efundachannel/?ref=pages_you_manage Please LIKE, SHARE and SUBSCRIBE to our channel eFunda channel . Regards, Team eFunda
